We design PCBs using Siemens Xpedition
We specialize in the design of printed circuit boards in Siemens Xpedition, formerly Mentor Graphics.
WHAT WE OFFER
+420 703 668 993
Contact us at info@bethewire.com for more information about our PCB design services in Xpedition system.
PCB design in Xpedition & Consulting @ All Right Reserved 2026
PCB Design
Design Optimization and Review
- Multi-layer PCB layout (HDI included)
- High-Speed design
- Implementation of Design for Excellence (DfM, DfA, DfT)
- Engineering for serial production
- Stack-up definition
- Impedance control
- Redesign and modernization of existing boards
- Component footprint creation and library management
- Support for rigid-flex and flexible PCB designs
- Compliance with industry standards as well as the customer’s internal standards and guidelines
- Generation of full manufacturing data packages (Gerber, drill files, BOM, pick & place)
- We will review your design
- Identification and resolution of potential production risks before fabrication
- Thorough design review focused on manufacturability, reliability, and cost efficiency
Consultation
Technical consulting focused on design strategy, technology selection, risk reduction, and manufacturability throughout the entire development process.
Legacy PCB Redesign & Migration
Design Recovery & Reconstruction
- Migration of legacy PCB projects into Xpedition design environments, combined with redesign to meet current manufacturing standards, component availability, and performance requirements.
- Or if you need an exact 1:1 redesign, let's do it this way. As you wish.
- Restoration of designs that cannot be properly annotated or opened
- You are not able to open a design? Contact us!
From design to production
We can arrange manufacturing and assembly of your PCBs with local suppliers.
Prototype 3D printing
3D printing from our PCB data or your files. Mainly PLA and PETG - other materials on request.
